This is a wearable scanning device that frees the brain and hands and improves work efficiency. Adopting modular design, detachable battery, communication charging gateway, combined with enterprise-level Android intelligent system, the customized Android platform adopts enterprise-level deeply customized Android platform to provide familiar operation and development, and make application development required for the workflow easier and more effective, and can provide development guides for different scenarios. Through WiFi and Bluetooth connections, supervisors and employees can understand real-time work status and guide them on the next job. It is a multifunctional mobile scanning device.
Different wearing methods adapt to the needs of different scenes, such as wearing gloves for handling scenes, wearing lanyards for retail scenes, etc. The operation can also complete the task content through scanning the code or voice assistance. Operators can also confirm the progress of the workflow through the screen or sound, vibration, and indicator lights.
| Processor：ARM Cortex-A53 2.0GHz |
| Operating system：Android 10.0 |
| Memory：16GB ROM + 2GB RA |
| LED indication：R、G、B |
| Number of scanning：8400 |
| Mainframe size：60mm long * 50mm wide * high 22mm |
| Base size：65mm long * 55mm wide * high 8mm |
| Weight：68g(the mainframe does not contain gloves) |
| Capture lens：5 million pixels, autofocus |
| Touch panel：Corning gorilla glass， |
| Industrial grade capacitive screen |
| Single point capacitive touch |
| Battery：Lithium battery 3.7V power supply, |
| 1000mAh, removable battery |
| Charge：Bottom seat charge, 5V/1A |
| Network and connection：Wi-Fi、BT 5O LE |
| Scan Notification：Scan prompt (red, green and blue) |
| audio prompt |
| Charging tip：Tricolor light (red light indicates charging |
| The green light indicates that it is full) |
| Sound：External speakers with maximum volume up to 90db |
| Number of scanning：1 second-7500 times |
| Button：Power button: long press switch function |
| Return button: return to the previous menu function |
| Volume +: volume plus volume -: volume reduction |
| Interface: bottom 6pogopin interface |
| Standard: gloves, Android smart host, battery, |
| communicable magnetic charging base |
| Optional: Bluetooth charging communication base, |
| USB charging line, 4-seat charging |
| Scanner performance |
| Resolution：2400280 LCD IPS |
| Lighting: 5000k white LED |
| Scanning range: horizontal: 44.3 °; vertical: 28.4 °; |
| diagonal 51 ° |
| Scan trigger: touch screen trigger, you can click the screen |
| scan button to trigger, press the button to trigger, you can |
| wear it on your hand, press the glove to trigger. |
| Supported code |
| Both 1D and 2D code reading scanning accuracy are supported:1D(≥ 3.3mil) /2D(≥ 5Mi) |
| Scanning distance：3cm-70cm (depending on different barcode density and code system) |
| Decoding ability：UPC/EAN,Code128,Code39,Code93 Code11,Interleaved 2 of 5,Discrete 2 of 5, Chinese 2 of 5,Codabar,MSI,RSS ；PDF417, MicroPDF417,Composite,RSS,TLC-39, Data matrix,QR code,Micro QR code,Aztec, Postal Codes,US PostNet,US Plane,UK Postal Japan Postal Dutch Postal,KIX |
| Environmental characteristics / level of protection |
| Operating temperature：- 5℃~50℃ |
| Working humidity：<80% |
| Fall：1.2 meters fall on six sides |
| Roll：0.5 meter ground roll 500 times |
| Protection grade：IP56 |
| Vibrate：With vibrating motor |
| Trigger scan: button trigger, self-induction trigger |
| Bluetooth: Bluetooth5.0. Support for BLE |
| Wireless LAN: Wifi 802.11 a/b/g/n/r/ac 2.4G+5G, supports fast roaming |
